Monocular Ground Normal Prediction for the Road Ahead

Robust fusion of monocular and inertial data has the potential to offer a low-cost alternative for ground surface normal prediction ahead, compared to more expensive sensors, such as LiDAR. Yet robust camera-based prediction remains challenging, particularly for steep grades and texture-poor, ho- mogeneous road surfaces.

To address these issues, we propose an enhanced monocular camera-IMU fusion pipeline incorporating a lightweight transformer-based feature matcher for improved correspondence accuracy, and robust temporal filtering, using a SLERP filter, to enhance consistency and reduce drift. To enable rigorous benchmarking and reproducibility, we also standardize the evaluation protocol and release a novel dataset containing synchronized camera, LiDAR, and IMU-derived pose data, specifically captured across diverse incline and decline scenarios.

Extensive continuous validation demonstrates that our method significantly improves both accuracy and temporal stability over existing approaches, setting a new state of the art for robust, continuous ground normal estimation ahead. The proposed pipeline and dataset are publicly available at: https://norbertmarko.github.io/imu_cam_normal_prediction/.
